DORMER F2721.1/2 DIENUT 1.1/2 INCH X 11 5978702
Die nuts F272
References
dormer:F2721.1/2
rubix:117A2056
ean:7320760217382
Technical specifications
| Threading | 1-1/2 |
|---|---|
| Wrench size | 85 mm |
| Cage thickness | 22 mm |
Product details : DORMER F2721.1/2 DIENUT 1.1/2 INCH X 11 5978702
HSS die nut for gas thread DIN 382 for non-alloyed steel <850 N/mm². Cast iron Aluminium en aluminium- magnesium alloys Si <10%.
Applications
• Machining steel soft steel (<120 HB <400 N/mm²)
• Construction steel carburised steel (<200 HB <700 N/mm²)
• Carbon steel (<250 HB <850 N/mm²)
• Cast Iron lamellar (<150 HB >500 N/mm ²)
• Cast iron lamellar (> 150<300 HB >500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Aluminium Magnesium non-alloyed (<100 HB <350 N/mm²)
• Aluminium alloyed Silicon 0.5% (<150 HB <500 N/mm²)
• Aluminium alloyed Silicon > 0.5% < 10% (<120 HB <400 N/mm²)
• Construction steel carburised steel (<200 HB <700 N/mm²)
• Carbon steel (<250 HB <850 N/mm²)
• Cast Iron lamellar (<150 HB >500 N/mm ²)
• Cast iron lamellar (> 150<300 HB >500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Aluminium Magnesium non-alloyed (<100 HB <350 N/mm²)
• Aluminium alloyed Silicon 0.5% (<150 HB <500 N/mm²)
• Aluminium alloyed Silicon > 0.5% < 10% (<120 HB <400 N/mm²)
Technical specifications
Attributes
| Threading | 1-1/2 |
|---|---|
| Wrench size | 85 mm |
| Cage thickness | 22 mm |
| Body material | hss |
Show UNSPSC/ECL@SS
£ 519.75 excl. VAT
/ Each
£ 623.70 incl. VAT
Usually arrives within 14 working days
