INA PCJTY45-XL FLANGED BEARING HOUSING UNIT2 HOLE WITH RADIAL INSERT B
Housing Unit
References
ina:PCJTY45-XL
rubix:238A3205
manufacturer :0009492720000
ean:4012802802184
Technical specifications
| Inner diameter | 45 mm |
|---|---|
| Width | 54.5 mm |
| Fixation centre-to-centre distance | 111 mm |
Product details : INA PCJTY45-XL FLANGED BEARING HOUSING UNIT2 HOLE WITH RADIAL INSERT B
two-bolt flanged housing units, cast iron, grub screws in inner ring, P seals
Technical specifications
Attributes
| Inner diameter | 45 mm |
|---|---|
| Width | 54.5 mm |
| Fixation centre-to-centre distance | 111 mm |
| Material | cast iron |
| Height | 180 mm |
| Length | 111 mm |
| Series | pcjty |
| Total bearing width | 54.5 mm |
| Diameter of fixation holes | 14 mm |
| Number of holes | 2 |
| Basic static load, radial - C0r | 20400 N |
| Basic dynamic load, radial - Cr | 34500 N |
| Outer diameter | 180 mm |
Show UNSPSC/ECL@SS
£ 46.44 excl. VAT
/ Each
£ 55.73 incl. VAT
Usually arrives within 14 working days
