DORMER E5503/8NO7 TAP 3/8 INCH X 19 5977475
Machine thread-cutters E550
References
dormer:E5503/8NO7
rubix:1071700
ean:7320760159446
Technical specifications
| Total length | 75 mm |
|---|---|
| Body material | HSS |
| Type | British blind bores and through-bores |
Product details : DORMER E5503/8NO7 TAP 3/8 INCH X 19 5977475
HSS Machine thread-cutters for Rc thread uncoated ISO 2284 shape C straight grooves 1.5xD blind and continual holes for cast iron and copper.
Applications
• Cast Iron lamellar (<150 HB >500 N/mm ²)
• Cast iron lamellar (>150<300 HB >500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Ductile cast iron/malleable cast iron (>200<300 HB >700<1000 N/mm²)
• Copper (<100 HB <350 N/mm²)
• Cast iron lamellar (>150<300 HB >500<1000 N/mm²)
• Ductile cast iron/malleable cast iron (<200 HB <700 N/mm²)
• Ductile cast iron/malleable cast iron (>200<300 HB >700<1000 N/mm²)
• Copper (<100 HB <350 N/mm²)
Technical specifications
Attributes
| Total length | 75 mm |
|---|---|
| Body material | HSS |
| Type | British blind bores and through-bores |
| With cooling spray | No |
| Drilling diameter | 14.75 mm |
| Square drive adapter | 12.5 mm |
| Coating | Bright |
Show UNSPSC/ECL@SS
£ 115.70 excl. VAT
/ Each
£ 138.84 incl. VAT
Usually arrives within 14 working days
