PTN PILLOW BLOCK UP000
Pillow Block
References
ptn:UP000
rubix:246A7871
manufacturer :893679
ean:3660338461361
Technical specifications
| Inner diameter | 10 mm |
|---|---|
| Fixation centre-to-centre distance | 53 mm |
| Shaft Height | 18 mm |
Product details : PTN PILLOW BLOCK UP000
Zinc alloy pillow block. Housing inserts consist of ball bearings and can be available in different materials. The insert bearing is a single row deep groove ball bearing with a convex-sphered outside diameter The external grease nipple is used for lubricating the ball bearing.
Strengths
High cost efficiency
High versatility
The inserted ball bearing can accommodate moderate initial misalignment, but normally can not permit axial displacement
Ready for mounting units
Lubricated and sealed bearing
Applications
Agriculture
Construction machinery
Food and beverages
Conveyors
Packaging
Power transmission
Material handling
General engineering applications
Technical specifications
Attributes
| Inner diameter | 10 mm |
|---|---|
| Fixation centre-to-centre distance | 53 mm |
| Shaft Height | 18 mm |
| Material | Zinc Alloy |
| Height | 35 mm |
| Length | 67 mm |
| Total bearing width | 14 mm |
| Series | UP000 |
| Weight | 0.08 kg |
| Number of holes | 2 |
| Width | 16 mm |
Show UNSPSC/ECL@SS
£ 3.87 excl. VAT
/ Each
£ 4.64 incl. VAT
In stock: Next day delivery
