TSUBAKI 0132100002 RS100-NP-1 CONNECTING LINK (COTTERPIN)
RS100-NP-1 Tsubaki ANSI connecting link (cotterpin)
References
tsubaki:RS100 NP 1 CL CP
rubix:267A0071
manufacturer :0132100002
ean:8718472007503
Technical specifications
| Chain | ANSI NP Chain |
|---|---|
| Chain pitch | 31.75 mm |
Product details : TSUBAKI 0132100002 RS100-NP-1 CONNECTING LINK (COTTERPIN)
ANSI NP Chain is a Tsubaki ANSI G7 chain that has been plated with Nickel. NP chain has a light corrosion resistance and an attractive appearance. NP chain is suitable for outdoor conditions exposed to water. There is a 15% reduction in Maximum Allowable Load compared to the corresponding ANSI G7 chain, so please take this into account when making your chain selection. The working temperature range is: -10°C to +60°C.
Technical specifications
Attributes
| Logistic Weight | 115 g |
|---|---|
| Chain | ANSI NP Chain |
| Chain pitch | 31.75 mm |
| Weight | 115 g |
| Inner width min. | 19.05 mm |
| Roller diameter | 19.05 mm |
| Plate height | 30.1 mm |
| Plate thickness | 4 mm |
| Pin length | 42.6 mm |
| Type | Roller Chain |
| Plate type | Link |
| Chain pin diameter | 9.54 mm |
Show UNSPSC/ECL@SS
£ 17.25 excl. VAT
/ Each
£ 20.70 incl. VAT
Usually arrives within 14 working days
