SKF KRV26PPXA STUD-TYPE TRACK ROLLER
Cam Follower (Stud-type Track Roller)
References
skf:KRV 26 PPXA
rubix:233A8452
manufacturer :139356
ean:7316571594347
Technical specifications
| Inner diameter | 10 mm |
|---|---|
| Width | 36 mm |
| Sealing | open |
Product details : SKF KRV26PPXA STUD-TYPE TRACK ROLLER
Cam followers (stud-type track rollers) are designed to run on all types of tracks and to be used in cam drives, conveyor systems, etc. They are based on a needle roller bearing with a threaded solid stud instead of an inner ring. They have a thick-walled outer ring with a crowned running surface and are supplied sealed and ready-to-mount. The bearings can be relubricated via the stud.
Strengths
- High radial load carrying capacity
- Accommodate axial loads due to skew or tilting
- Long service life
- Easy to mount
- Sealed for increased reliability, with relubrication feature
- Accommodate axial loads due to skew or tilting
- Long service life
- Easy to mount
- Sealed for increased reliability, with relubrication feature
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 36x26x26 mm |
|---|---|
| Logistic Weight | 61 g |
| Inner diameter | 10 mm |
| Width | 36 mm |
| Sealing | open |
| Bearing Clearance | cn |
| Series | krv |
| Material | bearing steel |
| Stat. Load rating | 11 N |
| Dyn. Load rating | 6.82 N |
| Outer diameter | 26 mm |
