BLICKLE B-ALEV 125K PRESSED STEEL FIXED CASTOR
Heavy duty drive wheel, with hub keyway, with Blickle Extrathane® polyurethane tread, with cast iron wheel centre
References
blickle:B-ALEV 125K
rubix:307A9734
manufacturer :286419
ean:4047526286415
Technical specifications
| Load capacity | 250 kg |
|---|---|
| Wheel diameter | 125 mm |
| Wheel width | 40 mm |
Product details : BLICKLE B-ALEV 125K PRESSED STEEL FIXED CASTOR
Tread:
- high-quality polyurethane elastomer Blickle Extrathane®, hardness 92 Shore A
- low rolling resistance
- high abrasion resistance
- high cut and tear propagation resistance
- colour light brown, non-marking, non-staining
- excellent chemical connection with the wheel centre
- rugged grey cast iron
- axle bore and hub keyway in accordance with DIN 6885
- lacquered, colour silver
- high chemical resistance to many aggressive substances
- operating temperature: -30 °C to +70 °C, temporarily up to +90 °C, reduced load capacity over +40 °C
Technical specifications
Attributes
| Logistic Weight | 1043 g |
|---|---|
| Load capacity | 250 kg |
| Wheel diameter | 125 mm |
| Wheel width | 40 mm |
| Wheel housing/rim material | aluminium |
| Running sole/tire material | rubber |
| Min. temperature | -20 °C |
| Max. temperature | 80 °C |
| Total height | 150 mm |
| Type of bearing | ball bearing |
| Running sole / tire colour | black |
| Shore A Hardness | 65 Shore |
| Plate width | 85 mm |
| Plate length | 100 mm |
| 150 mm | |
| 40 mm |
Show UNSPSC/ECL@SS
£ 36.88 excl. VAT
/ Each
£ 44.26 incl. VAT
Usually arrives within 14 working days
