BLICKLE 546077 LH-ALEV 127K-SG
Light duty swivel castor, with bolt hole fitting, with metal expander, with brake system 'stop-fix' Nylon wheel
References
blickle:LH-ALEV 127K-SG
rubix:245A8150
manufacturer :546077
ean:4047526546076
Technical specifications
| Load capacity | 300 kg |
|---|---|
| Wheel diameter | 125 mm |
| Wheel width | 50 mm |
Product details : BLICKLE 546077 LH-ALEV 127K-SG
Bracket: LKRA series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
- double ball bearing in the swivel head
- strong central kingpin
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: POA series
- high-quality nylon 6, impact resistant, hardness 70 Shore D, colour black
- high chemical resistance to many aggressive substances
- operating temperature: -25 °C to +80 °C, reduced load capacity over +35 °C
Technical specifications
Attributes
| Logistic Weight | 3130 g |
|---|---|
| Load capacity | 300 kg |
| Wheel diameter | 125 mm |
| Wheel width | 50 mm |
| Wheel housing/rim material | Aluminium |
| Running sole/tire material | Rubber |
| Type of bearing | Ball bearing |
| Running sole / tire colour | Grey |
| Shore A Hardness | 65 Shore |
| Min. temperature | -20 °C |
| Max. temperature | 80 °C |
| 170 mm | |
| 50 mm |
Show UNSPSC/ECL@SS
£ 122.63 excl. VAT
/ Each
£ 147.16 incl. VAT
Usually arrives within 14 working days
