BLICKLE SWIVEL CASTOR LKPA-POA-80G
Light duty swivel castor, with bolt hole fitting, with metal expander, with brake system 'stop-fix' Wheel, with solid rubber tyres, with synthetic rim, with steel thread guard, electrically conductive
References
blickle:LKPA-POA 80G
rubix:155A1545
manufacturer :576900
ean:4047526576905
Technical specifications
| Load capacity | 120 kg |
|---|---|
| Wheel diameter | 80 mm |
| Wheel width | 32 mm |
Product details : BLICKLE SWIVEL CASTOR LKPA-POA-80G
Bracket: LKRA series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
- double ball bearing in the swivel head
- strong central kingpin
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: VPA series
- tyre: high-quality solid rubber, hardness 80 Shore A, colour black, Non-staining
- rim: high-quality polypropylene, impact resistant, colour black
- high chemical resistance to many aggressive substances, except oils
- operating temperature: -20 °C to +60 °C, reduced load capacity over +30 °C
- electrical conductivity (ohmic resistance) ≤ 104 Ω
Technical specifications
Attributes
| Logistic Weight | 556 g |
|---|---|
| Load capacity | 120 kg |
| Wheel diameter | 80 mm |
| Wheel width | 32 mm |
| Wheel housing/rim material | polyamide |
| Running sole/tire material | polyamide |
| Shore D Hardness | 70 Shore |
| Type of bearing | plain bore |
| Running sole / tire colour | black |
| Min. temperature | -25 °C |
| Max. temperature | 80 °C |
| 111 mm | |
| 32 mm |
Show UNSPSC/ECL@SS
£ 14.21 excl. VAT
/ Each
£ 17.05 incl. VAT
Usually arrives within 14 working days
