DORMER A9776.0X260 DRILL 6.00 MM 5973148
Metal drills A977
References
dormer:A9776.0X260
rubix:1066017
ean:7320760148761
Technical specifications
| Drilling diameter | 6 mm |
|---|---|
| Total length | 260 mm |
| Length of cut | 180 mm |
Product details : DORMER A9776.0X260 DRILL 6.00 MM 5973148
HSS-E Extra long spiral drill with cylindrical shaft DIN 1869/2 PFX 130° uncoated 15xD for steel <1620 N/mm ².
FORET 6.0 EXTRALONG 260 QC A977 HSCO waist PFX
Applications
• Carbon steel (<250 HB <850 N/mm²)
• Alloyed steel (<250 HB <850 N/mm²)
• alloy steel hardened and tempered steel (>250<350 HB >850<1200 N/mm²)
• alloy steel hardened and tempered steel (> 350 HB >1200<1620 N/mm²)
• Alloyed steel (<250 HB <850 N/mm²)
• alloy steel hardened and tempered steel (>250<350 HB >850<1200 N/mm²)
• alloy steel hardened and tempered steel (> 350 HB >1200<1620 N/mm²)
Technical specifications
Attributes
| Drilling diameter | 6 mm |
|---|---|
| Total length | 260 mm |
| Length of cut | 180 mm |
| Din standard | DIN 1869/2 |
| Coating | Blank |
| Ratio of diameter to length of drill hole | 15xD |
| Machining material | Steel |
| Tip angle | 130 ° |
| Internal cooling | No |
| Tail diameter | 6 mm |
Show UNSPSC/ECL@SS
£ 47.60 excl. VAT
/ Each
£ 57.12 incl. VAT
Usually arrives within 14 working days
