BLICKLE GSPO 80/20K GSPO80-20K NYLON ROLLER
Pressed steel swivel castor, medium duty design, with top plate fitting, with brake system 'stop-fix' Cast iron wheel
References
blickle:GSPO 80/20K
rubix:202A5921
manufacturer :238568
ean:4047526238568
Technical specifications
| Load capacity | 1000 kg |
|---|---|
| Wheel diameter | 80 mm |
| Wheel width | 40 mm |
Product details : BLICKLE GSPO 80/20K GSPO80-20K NYLON ROLLER
Bracket: L series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
- double ball bearing in the swivel head
- strong central kingpin (from wheel Ø 150 mm)
- swivel head seal
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: G series
- rugged grey cast iron, hardness 180–220 HB, grease nipple, lacquered, colour silver
- chemical resistance to many aggressive substances
- operating temperature: -100 °C to +600 °C
- consider the surface pressure on sensitive floors due to high point loads
- provide adequate lubrication on a regular basis for plain bore version
- to be lubricated according to the application temperature
Technical specifications
Attributes
| Logistic Weight | 386 g |
|---|---|
| Load capacity | 1000 kg |
| Wheel diameter | 80 mm |
| Wheel width | 40 mm |
| Wheel housing/rim material | Polyamide |
| Running sole/tire material | Polyamide |
| Shore D Hardness | 80 Shore |
| Running sole / tire colour | Beige |
| Min. temperature | -20 °C |
| Max. temperature | 80 °C |
| 40 mm |
Show UNSPSC/ECL@SS
£ 36.59 excl. VAT
/ Each
£ 43.91 incl. VAT
Usually arrives within 14 working days
