GEDORE 2 LEG PULLER 7.5T 1.04/3A
Universal Puller
References
gedore:1.04/3A
rubix:133A2316
manufacturer :1307940
ean:4036976107227
Technical specifications
| Number of clamps/claws | 2 |
|---|---|
| Inner capacity | 420 mm |
| Exterior capacity | 350 mm |
Product details : GEDORE 2 LEG PULLER 7.5T 1.04/3A
Strengths
•For the safe and quick removal of pulleys, wheels, ball bearings, etc
Strong, ergonomically shaped cross beam with bending moment reinforcement
Due to the bending-moment reinforcement on its back face, the energy-saving design of the cross-beam means even stronger and safer pulling work
Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required
The quick-action adjustment feature supports the energy-saving and fast operation
Exchangeable spindle tip (ball or tip)
Upgradeable with hydraulic spindle (see table)
Strong, ergonomically shaped cross beam with bending moment reinforcement
Due to the bending-moment reinforcement on its back face, the energy-saving design of the cross-beam means even stronger and safer pulling work
Scale for uniform adjustment of the puller legs. Allows centred pulling, with optimised application of force, even when extremely high pulling forces are required
The quick-action adjustment feature supports the energy-saving and fast operation
Exchangeable spindle tip (ball or tip)
Upgradeable with hydraulic spindle (see table)
Technical specifications
Attributes
| Number of clamps/claws | 2 |
|---|---|
| Inner capacity | 420 mm |
| Exterior capacity | 350 mm |
| Depth | 200 mm |
| Extraction force | 7.5 t |
| Diameter | 27 mm |
| Length | 423 mm |
| Type | Universal Puller |
Show UNSPSC/ECL@SS
£ 505.71 excl. VAT
/ Each
£ 606.85 incl. VAT
Usually arrives within 14 working days
