MITUTOYO 201-107 DIAL SNAP GAUGE WITHOUT INDICATOR
Dial Snap Gauge
References
mitutoyo:201-107
rubix:80015873
ean:4946368051406
Technical specifications
| Measuring range, minimum | 150 mm |
|---|---|
| Measuring range, maximum | 175 mm |
Product details : MITUTOYO 201-107 DIAL SNAP GAUGE WITHOUT INDICATOR
A Mitutoyo dial snap gauge designed for quick GO/NG judgement of diameters of cylinders and shafts. Anvils are chamfered for easy workpiece insertion. The dial indicator is optional, enabling the user to choose from the wide range available to best suit the application.
Strengths
•Wide, flat carbide anvils
You can adjust the measuring range with an adjustment nut
You can adjust the measuring range with an adjustment nut
Applications
For Quick GO/NG Judgement of Diameters of Cylinders and Shafts
Technical specifications
Attributes
| Measuring range, minimum | 150 mm |
|---|---|
| Measuring range, maximum | 175 mm |
| Spindle diameter | 12 mm |
| Drum diameter | 16 mm |
| Flatness of measuring surfaces | 1 µ |
| Parallelism | 5 µ |
Show UNSPSC/ECL@SS
£ 469.16 excl. VAT
/ Each
£ 562.99 incl. VAT
Usually arrives within 14 working days
