BLICKLE LKR-POTH125G-FI 537613 LKR-POTH 125G-FI
Heavy duty welded steel twin wheel swivel castor, heavy duty swivel head Nylon heavy duty wheel
References
blickle:LKR-POTH 125G-FI
rubix:228A6697
manufacturer :537613
ean:4047526537616
Technical specifications
| Load capacity | 350 kg |
|---|---|
| Wheel diameter | 125 mm |
| Wheel width | 40 mm |
Product details : BLICKLE LKR-POTH125G-FI 537613 LKR-POTH 125G-FI
Bracket: LSD series
- particularly robust welded steel construction, zinc-plated, yellow-passivated, Cr6-free
- axial grooved ball bearing ISO 104 and tapered roller bearing ISO 355 in the swivel head
- bolted and secured welded central kingpin, extremely strong
- dust and splash-proof
- grease nipple
Wheel: SPO series
- high-quality nylon 6, impact resistant, hardness 70 Shore D, extremely robust heavy-duty version, colour natural white
- high chemical resistance to many aggressive substances
- operating temperature: -20 °C to +80 °C, reduced load capacity over +35 °C
Technical specifications
Attributes
| Logistic Weight | 1344 g |
|---|---|
| Load capacity | 350 kg |
| Wheel diameter | 125 mm |
| Wheel width | 40 mm |
| Wheel housing/rim material | Polyamide |
| Running sole/tire material | Polyurethane |
| Min. temperature | -25 °C |
| Max. temperature | 70 °C |
| Total height | 155 mm |
| Type of bearing | Plain bore |
| Running sole / tire colour | Grey |
| Shore A Hardness | 94 Shore |
| Plate diameter | 88 mm |
| 155 mm | |
| 40 mm |
Show UNSPSC/ECL@SS
£ 79.96 excl. VAT
/ Each
£ 95.95 incl. VAT
Usually arrives within 14 working days
