FAG UCPA203-J7 PLUMMER BLOCK HOUSING UNITS UCPA CAST IRON WITH

Plummer block housing unit

References

Superseded Ref:-T-UCPA203

FAG:UCPA203-J7

Rubix:238A3337

Manufacturer :0821621400000

EAN:4047643337397

Inner diameter	17 mm
Fixation centre-to-centre distance	52 mm
Shaft Height	30.2 mm

Plummer block housing units UCPA, cast iron housing, with short base, radial insert ball bearing with grub screws in inner ring, RSR seals

Attributes

Logistic Weight	630 g
Inner diameter	17 mm
Fixation centre-to-centre distance	52 mm
Shaft Height	30.2 mm
Material	grey cast iron
Total bearing width	31 mm
Outer diameter	62 mm
Clamping	12.7 mm
Diameter of fixation holes	10 mm
Mounting typ	tapped base (short base)
Height	62 mm
Length	76 mm
Sealing	rsr seals
Lubrication	relubricatable; grease fitting m6x1
Series	ucpa
Weight	0.63 kg
Number of holes	2
Basic static load, radial - C0r	6600 N
Basic dynamic load, radial - Cr	13600 N
Width	76 mm

Show UNSPSC/ECL@SS

£ 15.89 ^{excl. VAT}

/ Each

£ 19.07 ^{incl. VAT}
