BLICKLE B-POEV 125G-FA PRESSED STEEL FIXED CASTOR
Pressed steel swivel castor, with bolt hole, with brake system 'stop-fix' Nylon wheel, with synthetic thread guard
References
blickle:B-POEV 125G-FA
rubix:307A9726
manufacturer :850382
ean:4047526164416
Technical specifications
| Load capacity | 250 kg |
|---|---|
| Wheel diameter | 125 mm |
| Wheel width | 37 mm |
Product details : BLICKLE B-POEV 125G-FA PRESSED STEEL FIXED CASTOR
Bracket: LER series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
- double ball bearing in the swivel head
- strong central kingpin
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: PO series
- high-quality nylon 6, impact resistant, hardness 70 Shore D, colour natural white
- with synthetic thread guard, small
- high chemical resistance to many aggressive substances
- operating temperature: -20 °C to +80 °C, reduced load capacity over +35 °C
Technical specifications
Attributes
| Logistic Weight | 1000 g |
|---|---|
| Load capacity | 250 kg |
| Wheel diameter | 125 mm |
| Wheel width | 37 mm |
| Wheel housing/rim material | Polyamide |
| Running sole/tire material | Rubber |
| Min. temperature | -25 °C |
| Max. temperature | 80 °C |
| Total height | 150 mm |
| Type of bearing | Plain bore |
| Running sole / tire colour | Black |
| Shore A Hardness | 65 Shore |
| Plate width | 85 mm |
| Plate length | 100 mm |
| 150 mm | |
| 40 mm |
Show UNSPSC/ECL@SS
£ 29.23 excl. VAT
/ Each
£ 35.08 incl. VAT
Usually arrives within 14 working days
