Thrust ball bearing SKF 53324 M, Inner diameter: 120 mm | Outer diameter: 210 mm | Width: 74.1 mm
Thrust Ball Bearing
References
skf:53324 M
rubix:102A7770
manufacturer :39921
ean:7316577298607
Technical specifications
| Inner diameter | 120 mm |
|---|---|
| Outer diameter | 210 mm |
| Width | 74.1 mm |
Product details : SKF THRUST BALL BEARING 53324 M
SKF thrust ball bearings are manufactured as single direction or double direction thrust ball bearings. They are designed to accommodate axial loads only and must not be subjected to any radial load.
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 74,1x210x210 mm |
|---|---|
| Logistic Weight | 10700 g |
| Inner diameter | 120 mm |
| Outer diameter | 210 mm |
| Width | 74.1 mm |
| Series | 533 |
| Material | Bearing steel |
| Cage | Brass |
| Reference speed | 1000 rpm |
| Limit speed | 1500 rpm |
| Basic static load, axial - C0a | 980000 N |
| Basic dynamic load, axial - Ca | 325000 N |
Show UNSPSC/ECL@SS
£ 902.55 excl. VAT
/ Each
£ 1,083.06 incl. VAT
Usually arrives within 14 working days
