SKF FY 1.15/16 TF/VA228 HIGH TEMPERATURE BEARINGS

Ball bearing unit

References

SKF:FY 1.15/16 TF/VA228

Rubix:237A4222

Manufacturer :114631

EAN:07316571381268

Inner diameter	49.213 mm
Width	60.6 mm
Fixation centre-to-centre distance	111 mm

4 bolt square flange block

Attributes

Logistics dimensions (L x W x H)	58,8x143x49,21 mm
Logistic Weight	2380 g
Inner diameter	49.213 mm
Width	60.6 mm
Fixation centre-to-centre distance	111 mm
Material	cast iron (housing);high temperature steel (bearing)
Sealing	one metal shield
Height	43 mm
Length	143 mm
Series	fy
Total bearing width	51.6 mm
Clamping	2.6 mm
Diameter of fixation holes	18.01 mm
Number of holes	4
Basic static load, radial - C0r	23201.9 N
Basic dynamic load, radial - Cr	35100.9 N
Outer diameter	118 mm
Weight	2.35 kg

Show UNSPSC/ECL@SS

£ 224.86 ^{excl. VAT}

/ Each

£ 269.83 ^{incl. VAT}
