SNR UCF317 BEARING UNIT
Flanged bearing housing unit SNR
References
snr:UCF317
rubix:205A9713
ean:3413529541874
Technical specifications
| Inner diameter | 85 mm |
|---|---|
| Width | 96 mm |
| Fixation centre-to-centre distance | 204 mm |
Product details : SNR UCF317 BEARING UNIT
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 300x286x110 mm |
|---|---|
| Logistic Weight | 15266 g |
| Inner diameter | 85 mm |
| Width | 96 mm |
| Fixation centre-to-centre distance | 204 mm |
| Series | UCF300 |
| Number of holes | 4 |
| Basic static load, radial - C0r | 96500 N |
| Basic dynamic load, radial - Cr | 132600 N |
| Outer diameter | 180 mm |
| Weight | 15.56 kg |
Show UNSPSC/ECL@SS
£ 215.97 excl. VAT
/ Each
£ 259.16 incl. VAT
Usually arrives within 14 working days
