BLICKLE HTH 83X115/30-114K ROLLERS
Pressed steel swivel castor, heavy duty design, with top plate fitting, with brake system 'stop-fix' Cast iron wheel
References
blickle:HTH 83X115/30-114K
rubix:227A6954
manufacturer :467514
ean:4047526467517
Technical specifications
| Load capacity | 1070 kg |
|---|---|
| Wheel diameter | 83 mm |
| Wheel width | 115 mm |
Product details : BLICKLE HTH 83X115/30-114K ROLLERS
Bracket: LH series
- strong pressed steel, zinc-plated, blue-passivated, Cr6-free
- heavy fork and top plate
- double ball bearing in the swivel head
- bolted and secured central kingpin, extremely strong
- particularly resistant to shocks and impact due to four specially-shaped, hardened bearing seats
Wheel: G series
- rugged grey cast iron, hardness 180–220 HB, grease nipple, lacquered, colour silver
- chemical resistance to many aggressive substances
- operating temperature: -20 °C to +120 °C
- consider the surface pressure on sensitive floors due to high point loads
- provide adequate lubrication on a regular basis for plain bore version
- to be lubricated according to the application temperature
Technical specifications
Attributes
| Logistic Weight | 1802 g |
|---|---|
| Load capacity | 1070 kg |
| Wheel diameter | 83 mm |
| Wheel width | 115 mm |
| Wheel housing/rim material | Metal |
| Running sole/tire material | Polyurethane |
| Min. temperature | -20 °C |
| Max. temperature | 70 °C |
| Running sole / tire colour | Brown |
| Shore A Hardness | 92 Shore |
| 115 mm |
Show UNSPSC/ECL@SS
£ 63.61 excl. VAT
/ Each
£ 76.33 incl. VAT
Usually arrives within 14 working days
