BLICKLE FIXED CASTOR BH-SPO 160K
Pressed steel swivel castor, with top plate fitting, with brake system 'stop-top' Wheel, with thermoplastic polyurethane tread, with nylon wheel centre, with synthetic thread guard
References
blickle:BH-SPO 160K
rubix:80102024
manufacturer :754078
ean:4047526077006
Technical specifications
| Load capacity | 850 kg |
|---|---|
| Wheel diameter | 160 mm |
| Wheel width | 50 mm |
Product details : BLICKLE FIXED CASTOR BH-SPO 160K
Bracket: LE series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
- double ball bearing in the swivel head
- swivel head seal
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: PATH series
- tread: high-quality thermoplastic polyurethane (TPU), hardness 94 Shore A, colour dark grey, non-marking, non-staining
- wheel centre: high-quality nylon 6, impact resistant, colour silver grey
- with synthetic thread guard, small
- very high chemical resistance to many aggressive substances
- operating temperature: -20 °C to +70 °C, temporarily up to +90 °C, reduced load capacity over +35 °C
Technical specifications
Attributes
| Logistic Weight | 2324 g |
|---|---|
| Load capacity | 850 kg |
| Wheel diameter | 160 mm |
| Wheel width | 50 mm |
| Wheel housing/rim material | Polyamide |
| Running sole/tire material | Polyamide |
| Min. temperature | -20 °C |
| Max. temperature | 80 °C |
| Total height | 202 mm |
| Type of bearing | Ball bearing |
| Running sole / tire colour | Beige |
| Plate width | 110 mm |
| Plate length | 140 mm |
| 202 mm | |
| 50 mm |
Show UNSPSC/ECL@SS
£ 80.63 excl. VAT
/ Each
£ 96.76 incl. VAT
Usually arrives within 14 working days
