Thrust ball bearing SKF 51334 M, Inner diameter: 170 mm | Outer diameter: 280 mm | Width: 87 mm

Thrust Ball Bearing

See technical information

References

SKF:51334 M
Rubix:102A8503
Manufacturer :39758
EAN:7316571068428
brand logo

Technical specifications

Inner diameter170 mm
Outer diameter280 mm
Width87 mm
See all Specifications

Product details : SKF THRUST BALL BRG 51334 M

SKF thrust ball bearings are manufactured as single direction or double direction thrust ball bearings. They are designed to accommodate axial loads only and must not be subjected to any radial load.

Strengths

- Separable design facilitates mounting/dismounting and maintenance inspections
- Interchangeable components
- Ground bore of shaft washers enable interference fit

Technical specifications

Attributes
Logistics dimensions (L x W x H)87x280x280 mm
Logistic Weight21611 g
Inner diameter170 mm
Outer diameter280 mm
Width87 mm
Type of bearingsimple effect
Series513
Materialbearing steel
Cagebrass
Weight22 kg
Thickness87 mm
Reference speed800 rpm
Sealingopen (no seals)
Precisionp0 (normal / abec 1)
Basic dynamic load, axial - Ca468000 N
£ 3,529.97 excl. VAT
/ Each
£ 4,235.96 incl. VAT
  • Usually arrives within 14 working days
