Thrust ball bearing SKF 53322 M, Inner diameter: 110 mm | Outer diameter: 190 mm | Width: 67.2 mm
Thrust Ball Bearing
References
skf:53322 M
rubix:102A7772
manufacturer :39920
ean:7316570598179
Technical specifications
| Inner diameter | 110 mm |
|---|---|
| Outer diameter | 190 mm |
| Width | 67.2 mm |
Product details : SKF THRUST BALL BEARING 53322 M
SKF thrust ball bearings are manufactured as single direction or double direction thrust ball bearings. They are designed to accommodate axial loads only and must not be subjected to any radial load.
Technical specifications
Attributes
| Logistics dimensions (L x W x H) | 67,2x190x190 mm |
|---|---|
| Logistic Weight | 7780 g |
| Inner diameter | 110 mm |
| Outer diameter | 190 mm |
| Width | 67.2 mm |
| Series | 533 |
| Material | Bearing steel |
| Cage | Brass |
| Reference speed | 1200 rpm |
| Limit speed | 1600 rpm |
| Basic static load, axial - C0a | 815000 N |
| Basic dynamic load, axial - Ca | 281000 N |
Show UNSPSC/ECL@SS
£ 697.77 excl. VAT
/ Each
£ 837.32 incl. VAT
Usually arrives within 14 working days
