Tapered roller bearing Timken LM 328448/LM328410, Outer diameter: 187.325 mm | Inner diameter: 139.7 mm | Width: 28.575 mm
Tapered Roller Bearing
References
timken:LM 328448/LM328410
rubix:100A8266
ean:0053893784878
Technical specifications
| Inner diameter | 139.7 mm |
|---|---|
| Outer diameter | 187.325 mm |
| Width | 28.575 mm |
Product details : TIMKEN LM328448-99401 TAPERED ROLLER BEARING
This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts: the cone (inner ring) assembly and the cup (outer ring). It is typically mounted in opposing pairs on a shaft.
Strengths
•These maximum fillet radii will be cleared by the bearing corners
These maximum fillet radii will be cleared by the bearing corners
Negative value indicates effective center inside cone backface
These factors apply for both inch and metric calculations. Consult your Timken representative for instruction on use
These maximum fillet radii will be cleared by the bearing corners
Negative value indicates effective center inside cone backface
These factors apply for both inch and metric calculations. Consult your Timken representative for instruction on use
Technical specifications
Attributes
| Inner diameter | 139.7 mm |
|---|---|
| Outer diameter | 187.325 mm |
| Width | 28.575 mm |
| Series | LM328400 |
| Material | Stamped Steel (Cage) |
| Cage | Steel |
| Total bearing width | 28.575 mm |
| Standard | ISO |
| Basic static load, radial - C0r | 375000 N |
| Basic dynamic load, radial - Cr | 58800 N |
Show UNSPSC/ECL@SS
£ 686.81 excl. VAT
/ Each
£ 824.17 incl. VAT
Usually arrives within 14 working days
